LED NAVIGATION LIGHT – OP5000 – AMAZONIA MIRIM 5 – SW – INTEGRATE BI-DIMENSIONAL LIGHT 5 IN 1

SW VERSION

5 IN 1:Tri-color Navigation light, Anchor light, Emergency Strobe, Switches on-off automatically: at dawn at night and during storms or fog and Bi-Dimensional VLE System.

OPTOLAMP New line

The assembly of the electronics is similar to that used in the Military and Aerospace area: it is absolutely reliable.

GLOBAL WARRANTY: 3 YEARS

NEW“AMAZNIA 5“
VLE Systemnow with two functions:1-High Light Emission up to 4.2NM for Aerial Rescue. 2-In the Navigation Light function, the VLE System will adjust its intensity accordingly to illuminate only the Wind indicator on the top.
LS:New high sensitivity light sensor.
Sector 4:Theoptical system upgrade for the traditional bi-dimensionalOPTOLAMPlens, enables precise focusing.
OPTION:Amaznia 5 Aluminum: to replace previous Optolamp models. Simple installation without modifications (aluminum base).

RFI/EMI: absolutely FREE.

TDPSPro System –safe signalization:even if there is a defect in the system, the safety of the boat will always be maintained (it TDPS System acts as a second lamp in the event of a system failure).
Note:TDPS Pro Systemis an exclusive Optolamp characteristic.

UltraLowConsumtion UBC– First Integrated LED Light in the market.
ABSOLUTE SAFE SIGNALIZATION: MAXIMUM LIGHT INTENSITY WITH DISCHARGED BATTERIES. DRAWS 18 TIMES LESS ENERGY.

Amaznia model Versions:

Amaznia 5 “Classic”Version:4 wires are needed for: Tricolor, Anchor and Strobe Light. Standard Installation with the original boat panel switches.

Amaznia 5“SW”Version:Only 2 wires for: Tricolor and Anchor Light; or 3 wires to add Strobe Light function. This version use a mode 3 positions selector: standard switch ON-OFF-ON, or theOptolampSW3 Accessory (Not provided).

Description:
Simple Installation: Base in Delrin block. Waterproof (IP 67), connector (OptionalOptolampAccessory: C4 –Not provided).
OPTION: Amaznia 5 Aluminum: to replace previous Optolamp models. Simple installation without modifications (aluminum base).
It can work up to 40 nights with a 12V/75A battery without recharge it.
Consumes 18 times less energy.
Show the Top Wind Indicator.
Total resistance against mechanic stress.
Warranty HE: 3 years.
Patented.

Specifications:

Weight: 225 gr
Height: 125 mm.
Diameter: 60 mm.
Base: Delrin block, very fast installation.
Power source: 10,6V to 14,4V.
Option 24V:V1830 Optolamp Converter -Notprovided.
ConsumptionUBC: 0,126A to 0,155A.
Horizontal range: minimum 2,2 NM.
In accordance with the COLREG Norms.
Vertical rangeVLE system: up to 4,2 NM.
Switches on-off automatically: at dawn at night and during storms or fog.
LED life: minimum 50000 hs.

Accessories:

-OptolampBox Switch S-310 –Not provided.
-Optolamp SW3 Accessory: For Amaznia Mirim 5 > SW version –Not provided.
-Waterproof (IP 67), connector C4 OptolampAccessory –Not provided.
-New Electronic 24V Converter V1830–Not provided.

OPTOLAMPsignalization products do not cause RFI-EMI interference on the boat equipment.

Optolamp and the Ecology:

Some materials used in different manufacture parts of our products are originally in the market, our ecological policy is to avoid greater consumption of raw material, energy and matrix tools.
